2"

Basic Info.

Model NO.	TWG-IIA
Phase	Single Phase/Three Phase
Transport Package	Free of Fumigation Packing Carton
Specification	2′′-12′′ SCH40/10S/55/10/5 STEEL PIPE
Trademark	TUWEI
Origin	China
HS Code	8462490000
Production Capacity	50, 000 PCS/Year

Product Description

Product Description
Featuring
1. This machine is designed for grooving 2"-12" steel pipes2. Powered by high-performance gear reducing motor contributing to compact size and low noise3. Unique integral hydraulic pump structure and groove depth limitation device ensure high quality grooves and high working efficiency
Specifications

Parameter

Art No.	Phase	Voltage	Frequency
08.01.002.01	Single Phase	110/120/220/230/240V	50/60HZ
08.01.002.02	Three Phase	220/380/415/440V	50/60HZ

Standard Equipment (For SCH40 steel pipe)

Art No.	Description	N.W(kgs)	Ref No.
09.02.031	Pipe stand	18	(2)
03.01.01.016	Knurl wheel φ60-φ76	0.545	(3)
03.01.01.015	Knurl wheel φ89-φ168	1.265	(4)
03.01.01.014	Knurl wheel φ219-φ325	1.415	(5)
03.01.01.026	Pinch roller φ60-φ168	0.885	(6)
03.01.01.025	Pinch roller φ219-φ325	0.85	(7)

Optional Equipment (For SCH10S SCH5S SCH10 SCH5 thin wall steel pipe)

Art No.	Description	N.W(kgs)
09.03.009	Thin-wall knurl wheel φ60-φ76	0.55
09.03.010	Thin-wall knurl wheel φ89-φ168	1.28
09.03.011	Thin-wall knurl wheel φ219-φ325	1.43

Reminding:Please select TWG-IVA if groove large number of 12inch pipes
